Periodic maintenance and adjustment
6-34
6
12. Install the grab bar by installing the
bolts, and then tightening them to
the specified torque.
13. Close the seat.
EAU43054
Replacing a front turn signal
light bulb
1. Place the vehicle on the center-
stand.
2. Remove the turn signal light bulb
socket (together with the bulb) by
turning it counterclockwise.
3. Remove the burnt-out bulb by
pulling it out.
4. Insert a new bulb into the socket.
5. Install the socket (together with
the bulb) by turning it clockwise.
Tightening torque:
Grab bar bolt:
17 Nm (1.7 m·kgf, 12 ft·lbf)
1. Turn signal light bulb socket
1. Turn signal light bulb
U2DSE0E0.book Page 34 Thursday, March 19, 2015 10:34 AM
