● YST-SW015
Type / 型式 Advanced Yamaha Active Servo Technology
Output Power / 出力
100Hz, 5 Ω, 10 % T.H.D 70 W
Input Sensitivity / 入力感度
INPUT (PJ), 100Hz, 70 W/5 Ω, L + R 30 mV
Input Impedance / 入力インピーダンス
INPUT (PJ) 12 kΩ
Frequency Response / 再生周波数帯域 30 Hz to 200 Hz
Driver / スピーカーユニット
16 cm (6.5") Cone, Magnetic Shielding Type
Input Section / 入力部 INPUT: RCA pin jack
Operation Section / 操作部
FRONT PANEL
STANDBY/ON Switch, B.A.S.S Switch, Volume
Control, High Cut Control, LED Indicator
REAR PANEL
Power Switch, Auto Standby Switch (HIGH/LOW/
OFF), Phase Switch (NORM/REV), Voltage
Selector (R, T, K models)
Power Supply / 電源
U, C models AC 120 V, 60 Hz
R, T, K models AC 110-120/220-240 V, 50/60 Hz
A model AC 240 V, 50 Hz
B, G models AC 230 V, 50 Hz
J model AC 100 V, 50/60 Hz
Power Consumption / 消費電力
U, C, R, T, K, A, B, G models 70 W
J model 38 W
Standby Power Consumption / 待機消費電力 0.8 W
Dimensions (W x H x D) / 寸法（幅×高さ×奥行き）
280 x 325 x 320 mm
(11" x 12-13/16" x 12-5/8")
Weight / 質量 9.2 kg (20 lbs. 4 oz.)
Finish / 仕上げ Cherry, Black, Silver
● NX-430P
Type / 型式 2-way Acoustic Suspension
Magnetic Shielding Type
Driver / スピーカーユニット
Coaxial 2-way 5 cm (2") Cone and 1.3 cm (1/2")
Dome Magnetic Shielding Type x 1
Full Range 5 cm (2") Cone Magnetic
Shielding Type x 1
Frequency Response / 再生周波数帯域
70 Hz to 60 kHz
Impedance / インピーダンス 6 Ω
Nominal Input / 許容入力 30 W
■ SPECIFICATIONS
Maximum Input / 最大入力 100 W
Sensitivity / 出力音圧レベル 85 dB/2.83 V/m
Crossover Frequency / クロスオーバー周波数 7 kHz
Input Terminal / 入力端子 Push Type
Dimensions (W x H x D) / 外形寸法（幅×高さ×奥行き）
87 x 184 x 147 mm
(3-7/16" x 7-1/4" x 5-13/16")
Weight / 質量 1.2 kg (2 lbs. 10 oz.)
Finish / 仕上げ Cherry, Silver, Black
● NX-C430
Type / 型式 2-way Acoustic Suspension
Magnetic Shielding Type
Driver / スピーカーユニット
Coaxial 2-way 5 cm (2") Cone and 1.3 cm (1/2")
Dome Magnetic Shielding Type x 1
Full Range 5 cm (2") Cone Magnetic
Shielding Type x 2
Frequency Response / 再生周波数帯域
70 Hz to 60 kHz
Impedance / インピーダンス 6 Ω
Nominal Input / 許容入力 30 W
Maximum Input / 最大入力 100 W
Sensitivity / 出力音圧レベル 86 dB/2.83 V/m
Crossover Frequency / クロスオーバー周波数 7 kHz
Input Terminal / 入力端子 Push Type
Dimensions (W x H x D) / 外形寸法（幅×高さ×奥行き）
273 x 81 x 147 mm
(10-3/4" x 3-3/16" x 5-13/16")
Weight / 質量 1.7 kg (3 lbs. 12 oz.)
Finish / 仕上げ Cherry, Silver, Black
● Accessories / 付属品
Speaker cable (4 m) x 3
Speaker cable (15 m) x 2 [NS-P430]
Speaker cable (15 m) x 3 [NS-P436]
Subwoofer cable (3 m) x 1
Non skid pad x 4
Fastener x 2
* Specifications subject to change without notice.
U ....... USA model
C ....... Canadian model
A ....... Australian model
B ....... British model
G ....... European model
R ....... General model
T ....... Chinese model
K ....... Korean model
J ....... Japanese model
