10
PSR-A350 Owner’s Manual
Setting Up
Power Requirements
Although the instrument will run either from an AC
adaptor or batteries, Yamaha recommends use of an
AC adaptor whenever possible. An AC adaptor is
more environmentally friendly than batteries and
does not deplete resources.
Using an AC adaptor
1 Make sure that the power of the instrument is off
(the backlight display is off).
2 Connect the AC adaptor to the DC IN jack (power
supply jack).
3 Plug the AC adaptor into an AC outlet.
Notice for the AC adaptor
Depending on your particular locale, the AC adaptor
having a separable plug should be used. If the plug is
accidentally removed from the AC adaptor, make
sure to follow the explanations below for your safety.
Reattaching the plug removed from the AC
adaptor
Without touching the metallic section, slide the plug
into place as shown below then push it in completely
until you hear the click sound.
• Use the specified adaptor (page 48) only. Using the
wrong adaptor can result in damage to the instrument
or overheating.
• When setting up the product, make sure that the AC
outlet you are using is easily accessible. If some trou-
ble or malfunction occurs, immediately turn off the
power switch and disconnect the plug from the outlet.
• After turning off the power, follow this procedure in reverse
order to disconnect the AC adaptor.
• Power will be automatically drawn from the AC adaptor if an
AC adaptor is connected while batteries are installed in the
instrument.
AC outlet
AC
adaptor
3
2
DC IN jack
(page 9)
• Make sure to keep the plug attached to the AC adaptor.
Using the plug alone can cause electric shock or fire.
• Never touch the metallic section when attaching the plug.
To avoid electric shock, short circuit or damage, also be
careful that there is no dust between the AC adaptor and
plug.
Plug
Slide the plug as
indicated
* The shape of the plug differs depending on locale.
To Next Page
