Yamaha R1 Series 2015 User Manual

SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
(ECU)
9-10
EAS31058
DIAGNOSTIC CODE: ACTUATOR OPERATION TABLE
Diagnostic
code No.
Item Actuation Procedure
30 Cylinder-#1 ignition coil Actuates the cylinder-#1 igni-
tion coil five times at one-
second intervals.
Illuminates the engine trou-
ble and system warning light.
Check that a spark is gener-
ated five times.
• Connect an ignition
checker.
31 Cylinder-#2 ignition coil Actuates the cylinder-#2 igni-
tion coil five times at one-
second intervals.
Illuminates the engine trou-
ble and system warning light.
Check that a spark is gener-
ated five times.
• Connect an ignition
checker.
32 Cylinder-#3 ignition coil Actuates the cylinder-#3 igni-
tion coil five times at one-
second intervals.
Illuminates the engine trou-
ble and system warning light.
Check that a spark is gener-
ated five times.
• Connect an ignition
checker.
33 Cylinder-#4 ignition coil Actuates the cylinder-#4 igni-
tion coil five times at one-
second intervals.
Illuminates the engine trou-
ble and system warning light.
Check that a spark is gener-
ated five times.
• Connect an ignition
checker.
34 Intake funnel servo motor Actuates the intake funnels
(up position down, position
for each six seconds).
Illuminates the engine trou-
ble and system warning light.
Check the operating of the
intake funnel servo motor.
36 Primary injector #1 Actuates the primary injec-
tor #1 five times at one-sec-
ond intervals.
Illuminates the engine trou-
ble and system warning light.
Check that primary injector
#1 is actuated five times by
listening for the operating
sound.
37 Primary injector #2 Actuates the primary injec-
tor #2 five times at one-sec-
ond intervals.
Illuminates the engine trou-
ble and system warning light.
Check that primary injector
#2 is actuated five times by
listening for the operating
sound.
38 Primary injector #3 Actuates the primary injec-
tor #3 five times at one-sec-
ond intervals.
Illuminates the engine trou-
ble and system warning light.
Check that primary injector
#3 is actuated five times by
listening for the operating
sound.
39 Primary injector #4 Actuates the primary injec-
tor #4 five times at one-sec-
ond intervals.
Illuminates the engine trou-
ble and system warning light.
Check that primary injector
#4 is actuated five times by
listening for the operating
sound.
40 Secondary injector #1 Actuates the secondary
injector #1 five times at one-
second intervals.
Illuminates the engine trou-
ble and system warning light.
Check that secondary injec-
tor #1 is actuated five times
by listening for the operating
sound.
41 Secondary injector #2 Actuates the secondary
injector #2 five times at one-
second intervals.
Illuminates the engine trou-
ble and system warning light.
Check that secondary injec-
tor #2 is actuated five times
by listening for the operating
sound.

Yamaha R1 Series 2015 Specifications

General

Bore x Stroke	79.0mm x 50.9mm
Compression Ratio	13.0:1
Fuel System	Fuel injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Transmission	6-speed; multiplate slipper clutch
Final Drive	Chain
Front Brakes	Dual 320mm hydraulic disc; ABS
Rear Brakes	220mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	190/55ZR17
Length	80.9 in
Width	27.2 in
Height	45.3 in
Seat Height	33.7 in
Wheelbase	55.3 in
Fuel Capacity	4.5 gal
Wet Weight	439 lb
Front Suspension	43mm inverted fork; fully adjustable
Rear Suspension	Single shock, fully adjustable; 4.7-in travel
Engine Type	998cc, liquid-cooled, DOHC 4-stroke, 4-valve
