4-10
EBU00080
Parking brake
Use the parking brake when you have to start
the engine or park the machine, especially on
a slope. Squeeze the clutch lever while push-
ing the button, then push in the lock plate to
apply the parking brake. Squeeze the clutch
lever to release the parking brake.
N
TE:
When the parking brake is used, engine
speed is limited to 2,300 r/min. Be sure the
parking brake is released before moving the
throttle lever. Otherwise, the engine will mis-
fire, preventing normal operation.
1. Button 2. Lock plate
1. Locked position
