DVD-E600MK2
23
MAIN (5) P.C.B. (Side B) Lead Free Solder Used MAIN (6) P.C.B. (Side B) Lead Free Solder Used
MAIN (7) P.C.B. (Side B) Lead Free Solder Used
■ PRINTED CIRCUIT BOARD (Foil side)
14
2
5
3
D21 C3
D22 C3
D501 B3
Q1 B6
Q2 B6
Q3 B6
Q4 B6
Q5 C5
• Semiconductor Location
Ref no. Location Ref no. Location
Q7 D6
Q8 D5
Q9 D5
Q10 D6
Q27 D3
Q28 D3
Q501 B4
Q504 C5
