DVD-E600MK2
31
P.C.B. MAIN
✻ New Parts
Ref. No. Part No. Description Markets
Chip Resistors
✻ New Parts
Ref. No. Part No. Description Markets
✻ New Parts ✻ New Parts
* WG111500 P.C.B. MAIN:SI BGE
* CB2 WG158500 CN.BS.PIN 30PTE52806
* CB4 WF730200 CN.BS.PIN 4PTE
* CB5 WF730500 CN.BS.PIN 9PTE
CB6 VB390600 CN.BS.PIN 10P
* CB9 WF730700 CN.BS.PIN 16PTE
CB14 VQ047500 CN.BS.PIN 20P
CB16 VB390300 CN.BS.PIN 7P
CB17 VB390200 CN.BS.PIN 6P
CB201 VM929900 CN.BS.PIN 15P
CB202 WB497100 CN 21PYKF41‑5044
CB204 VM859600 CN.BS.PIN 15P
CB205 VQ045000 CN.BS.PIN 20P
CB301 VK024800 CN.BS.PIN 4P
CB302 VB390200 CN.BS.PIN 6P
CB305 VB390100 CN.BS.PIN 5P
C1 UR847100 C.EL 10uF25V
C2‑3 US135100 C.CE.CHP 0.1uF16V
C4 UR847100 C.EL 10uF25V
C5 UR838100 C.EL 100uF16V
C6 UR837100 C.EL 10uF16V
C7‑8 US135100 C.CE.CHP 0.1uF16V
C9‑10 UR847100 C.EL 10uF25V
C11 US135100 C.CE.CHP 0.1uF16V
C12 UR838100 C.EL 100uF16V
C13 US135100 C.CE.CHP 0.1uF16V
C14‑15 UA653330 C.MYLAR 3300pF50VJ
C16‑19 UA652470 C.MYLAR 470pF50VJ
C20‑23 UR847100 C.EL 10uF25V
C24‑25 UA652220 C.MYLAR 220pF50VJ
C26 UR038100 C.EL 100uF16V
C28 US062220 C.CE.CHP 220pF50VB
C29 US135100 C.CE.CHP 0.1uF16V
C30 US061470 C.CE.CHP 47pF50VB
C31 US135100 C.CE.CHP 0.1uF16V
C32‑33 US062220 C.CE.CHP 220pF50VB
C34 UR819100 C.EL 1000uF6.3V
C35 UN837330 C.EL.BP 33uF16V
C36 UR819100 C.EL 1000uF6.3V
C37 UR838100 C.EL 100uF16V
C55 UR847100 C.EL 10uF25V
C57 US135100 C.CE.CHP 0.1uF16V
C58‑59 UR848100 C.EL 100uF25V
C60 UR847100 C.EL 10uF25V
C61 US135100 C.CE.CHP 0.1uF16V
C62‑63 UR039100 C.EL 1000uF16V
C64‑65 US064100 C.CE.CHP 0.01uF50VB
C66 UR847100 C.EL 10uF25V
P.C.B. MAIN P.C.B. MAIN
C67 US135100 C.CE.CHP 0.1uF16V
C201 US064100 C.CE.CHP 0.01uF50VB
C202 US135100 C.CE.CHP 0.1uF16V
C205‑213 US062220 C.CE.CHP 220pF50VB
C301 US064100 C.CE.CHP 0.01uF50VB
C302‑304 US062100 C.CE.CHP 100pF50VB
C501 US061220 C.CE.CHP 22pF50VB
C502 UM388100 C.EL 100uF10V
C503 US135100 C.CE.CHP 0.1uF16V
C504‑505 UR867220 C.EL 22uF50V
C506 US065100 C.CE.CHP 0.1uF50VB
C507 UM388100 C.EL 100uF10V
C508 US135100 C.CE.CHP 0.1uF16V
C509 US065100 C.CE.CHP 0.1uF50VB
C510 UM417220 C.EL 22uF50V
C511 US065100 C.CE.CHP 0.1uF50VB
C512 UR867220 C.EL 22uF50V
C513 US065100 C.CE.CHP 0.1uF50VB
C515 US062100 C.CE.CHP 100pF50VB
C516 US065100 C.CE.CHP 0.1uF50VB
C518‑520 US065100 C.CE.CHP 0.1uF50VB
C526 US064100 C.CE.CHP 0.01uF50VB
C530‑532 US062100 C.CE.CHP 100pF50VB
C536 US065100 C.CE.CHP 0.1uF50VB
D4‑10 WC398800 DIODE KDS160‑RTK
D18‑22 WC398800 DIODE KDS160‑RTK
D208 WC398800 DIODE KDS160‑RTK
D501 VU171900 DIODE.ZENR UDZ5.1B5.1V
D502‑504 VU172000 DIODE.ZENR UDZS5.6BTE‑175.6V
D505‑506 WC398800 DIODE KDS160‑RTK
IC1 X3204A00 IC PQ070XZ5MZP
IC2 X6040A00 IC AK4385ET
* IC3 XJ601A00 IC NJM78M08A8V
IC4 XS534A00 IC NJM78M05DL1A(TE1)
IC5 X3505A00 IC NJM2068MD‑TE2
IC6 XW939A00 IC TK15420MVIDEOAMP
IC8 XY071A00 IC HD74HC126FPBUSBU
IC9 X6509A00 IC ADG733
IC501 X5751A00 IC.CPU UPD16312GB‑3BS‑A
* JK1 WG158400 TERM.S S‑JACK
JK301 WD662100 JACK.PIN 4PJY‑2522
PJ1 V7720900 JACK.PIN LPR6520‑E510M
* PJ2 WG226800 JACK.PIN 2PRJ‑1144
* PJ201 WG139700 JACK.PIN 3PRJ‑1165
PN1‑7 V9637500 PIN L=70#18
PN8 V8637500 PIN L=50#18
Q1‑4 VZ725900 TR 2SD1938FS,T
Q5 VV655700 TR.DGT DTC144EKA
Q7 VV655700 TR.DGT DTC144EKA
Q8‑9 VV556400 TR 2SC2412KQ,R,S
Q10 VV655700 TR.DGT DTC144EKA
Q11 VV556400 TR 2SC2412KQ,R,S
Q12‑15 VV556500 TR 2SA1037KQ,R,S
Q20‑21 VV556500 TR 2SA1037KQ,R,S
Q22 VV655700 TR.DGT DTC144EKA
Q24 VV655700 TR.DGT DTC144EKA
Q25 VV556400 TR 2SC2412KQ,R,S
Q26 VV655700 TR.DGT DTC144EKA
Q27 VV556400 TR 2SC2412KQ,R,S
* Q28 WF764200 FET RSR025N03
Q201‑204 VZ725900 TR 2SD1938FS,T
Q501 VV556400 TR 2SC2412KQ,R,S
Q502 VP872700 TR 2SC4488S,T
Q503 VP872600 TR 2SA1708S,T
Q504 VV556500 TR 2SA1037KQ,R,S
R64‑65 VP940800 R.MTL.OXD 470Ω1W
R78‑79 HV753220 R.CAR.FP 2.2Ω1/4W
R510‑511 HV755470 R.CAR.FP 470Ω1/4W
R522‑523 VP939800 R.MTL.OXD 10Ω1W
ST301‑302 V4040500 SCR.TERM M3
SW501‑506 V4757100 SW.TACT EVQ11A
U1 WB001600 CN.PHOT.SN 1PGP1FA553TZ
U501 V8444900 L.DTCT GP1UM271XK
V501 WD602800 FL.DSPLY 7‑BT‑299GNK
% WD890100 SHEET/FL ORANGE:GD
WD890000 SHEET/FL BLUE:SI
RD350000 R.CHP 0Ω1/16WJ
RD353220 R.CHP 2.2Ω1/16WJ
RD354330 R.CHP 33Ω1/16WJ
RD354750 R.CHP 75Ω1/16WJ
RD355100 R.CHP 100Ω1/16WJ
RD355220 R.CHP 220Ω1/16WJ
RD355330 R.CHP 330Ω1/16WJ
RD355470 R.CHP 470Ω1/16WJ
RD355680 R.CHP 680Ω1/16WJ
RD356100 R.CHP 1KΩ1/16WJ
RD356220 R.CHP 2.2KΩ1/16WJ
RD356470 R.CHP 4.7KΩ1/16WJ
RD356680 R.CHP 6.8KΩ1/16WJ
RD357100 R.CHP 10KΩ1/16WJ
RD357220 R.CHP 22KΩ1/16WJ
RD357470 R.CHP 47KΩ1/16WJ
RD357560 R.CHP 56KΩ1/16WJ
RD358100 R.CHP 100KΩ1/16WJ
RD359100 R.CHP 1MΩ1/16WJ
● The chip resistor is not supplied as a replacement part.
* When a chip resistor is necessary, use the following part.
AAX60720: CHIP RESISTOR SAMPLE BOOK
%: Note on the MAIN P.C.B.
Of the MAIN P.C.B. part Nos., only the silver (SI) type part
Nos. are included in the table.
The only different part between the gold (GD) and silver (SI)
type parts is the sheet/FL that is attached to the fluorescent
character display tube. When a gold (GD) type MAIN P.C.B.
becomes necessary, order a silver (SI) type MAIN P.C.B.
and a gold (GD) type sheet/FL (WD890100) and replace the
sheet/FL of the silver (SI) type MAIN P.C.B. with the gold
(GD) type sheet/FL.
