DVD-E600MK2
33
* 1‑1 WG111500 P.C.B.ASS'Y MAIN SI
* 1‑101 WG127400 FRONTPANEL GD
* 1‑101 WG127300 FRONTPANEL SI
1‑102 WE493500 SUBPANEL‑DVD GD
1‑102 WE493400 SUBPANEL‑DVD SI
1‑103 V8785200 PANEL/SIDE H100
1‑104 WD607500 SHEET/WINDOW
1‑110 VQ368600 PUSHRIVET P3555‑B
1‑111 VF617600 PANHEADP‑TIGHTSCREW 2.6x8MFC2BL
* s 2 X7186A00 POWERSUPPLYUNIT 313924872062
* 3 X7187A00 MONOBOARD 313924886741
* 6 WG205300 DVDMECHANISMUNIT 313924872251
s 11 VN363600 POWERCABLE GE
s 11 WF723100 POWERCABLE 2m B
12 V2438700 CORDSTOPPER 10P1
* 14 WG226900 FLEXIBLEFLATCABLE 30P70mmP=1.0
* 15 WG227300 FLEXIBLEFLATCABLE 20P80mmP=1.25
* 16 WG227100 FLEXIBLEFLATCABLE 16P80mmP=1.0
17 MF115080 FLEXIBLEFLATCABLE 15P80mmP=1.25
* 18 WG227200 FLEXIBLEFLATCABLE 9P80mmP=1.0
* 19 WG227000 FLEXIBLEFLATCABLE 4P70mmP=1.0
20 VB933800 FERRITECORE BP53RB310190NOA
21 VU590000 BINDINGTIE CBTD001B
101 V7127400 TOPCOVER GD
101 V7127300 TOPCOVER SI
* 103 WG127200 REARPANEL
105 WD397500 BINDINGTIE MSF‑085
* 106 WG127600 LID/DVD GD
* 106 WG127500 LID/DVD SI
107 WE361000 SHEET/BARRIER
108 WF754600 BARRIERPSU
115 WC879000 DAMPER
116 VP857700 DAMPER 4x6x55
117 V7616600 DAMPER
118 V3688500 LEG M0080‑M0
* 119 WG085200 SUPPORT/PSU
121 WA602600 LOCKINGCARDSPACER KGLS‑8S
139 VQ368500 PUSHRIVET P3545‑B
140 WE774100 BINDHEADBONDINGB‑T.SCREW 3x8MFZN2B3
141 WE774300 BINDHEADB‑TIGHTSCREW 3x8MFZN2W3
142 VT669300 PWHEADB‑TIGHTSCREW 3x8‑8MFC2
143 WE936300 BINDHEADB‑TIGHTSCREW 3x6MFZN2W3
■ MECHANICAL PARTS
✻ New Parts
Ref.No. PartNo. Description Remarks Markets
✻ New Parts
144 WE774800 BINDHEADP‑TIGHTSCREW 3x8MFZN2W3
145 EP600790 FLATHEADB‑TIGHTSCREW 3x8MFZN2BL
146 VY712800 PWHEADB‑TIGHTSCREW 3x8‑8MFNI33
* 150 WG432900 PUSHRIVET P3535
% WD890100 SHEET/FL ORANGE GD
WD890000 SHEET/FL BLUE SI
ACCESSORIES
200 WD882600 REMOTECONTROL 313924871873
202 VV209200 VIDEOPINCABLE 1P1.0m
203 VY952200 AUDIOPINCABLE 2P1.0m1pc
204 WD865200 SYSTEMCONTROLCABLE 1P1.0m1pc
BATTERY,MANGANESE SUM‑3M2pcs
Ref.No. PartNo. Description Remarks Markets
