CS-R3 Owner’s Manual
17
F Channel Strip section (Bay L, Bay C, Bay R)
1 [ENCODER ASSIGN] key
Displays a screen that enables you to switch between
the Screen Encoder function and the Channel
Encoder function for bay C. You can use only the
Channel Encoder function for bay L, bay R, and
channel strips A and B.
2 [HOME] key
Recalls a group of settings for the bay. Press and hold
down this key to store the following settings:
• Layers and current screen data
• Selected channel/parameters on screen
3 [TOUCH AND TURN] knob
Controls the parameter of the knob you selected by
touching the touch screen.
4 [SHIFT] key
Combine with another key to perform a certain
function.
The following table shows an example of using the
[SHIFT] key combined with another key. For more
information, please refer to the RIVAGE PM series
Operation Manual.
5 [SENDS ON FADER] key
Turns SENDS ON FADER mode on and off. While
SENDS ON FADER mode is enabled, the input faders
will control the send levels of the corresponding
buses.
RANGE
AB
AB
GAIN
ENCODER
ASSIGN
HOME
VIEW
ASSIGN
SENDS ON
FADER
123456789101112
123456789101112123456789101112
USER DEFINED
KEY
THRESHOLD
ATTACK
ATTACK RELEASE
DECAYHOLD
KNEE
RATIO OUTGAIN
TOUCH AND TURN
E2
123456789101112
123456789101112
USER DEFINED
KEY
E1
GAIN
GAIN
GAIN
SENDS ON
FADER
SENDS ON
FADER
123456789101112
TALKB AC K
MONITORUSER DEFINED KEYS
1234
5678
9101112
1234
5678
9101112
BANK
CC
/ BANK
D
/
SYSTEM
POWER
A
B
USB
RECORDING
ON
DECDEC INCINC
OVERLAY UNDO
SCENE MEMORY
UPDATE PREVIEW
STORE RECALL
TOUCH AND TURN
SENDS ON
FADER
ENCODER
ASSIGN
HOME
1
2
3
4
5
Procedure Function
Press and hold down the
[SHIFT] key and press
multiple [SEL] keys.
Temporary link.
Controlling the parameter of
multiple channels
simultaneously.
To Next Page
