Yamaha RX-V2400 User Manual

16
CONNECTIONS
■ Connections for DVD playback
Connecting video components
GND
M
SUR
SUB
WOO
CENTER
SUB
WOOFER
MONITOR OUT
MULCH CH INPUT OUTPUT
AUDIO AUDIO VIDEO
S VIDEO
DVD
DTV
CBL
/SAT
VIDEO
R
L
R
L
IN
(
PLAY
)
IN
(
PLAY
)
OUT
(
REC
)
OUT
(
REC
)
CD-R
MD/TAPE
CD
PHONO
IN
OUT
OUT
ZONE 2
ZONE 3
DVR/
VCR 2
VCR 1
CD-R
IN
MAIN/SURROUND BACK
SURROUND
TUNER
75Ω
UNBAL.
AM
ANT
GND
FM ANT
COMPONENT VIDEO
P R
DVD
MONITOR OUT
DTV
P B Y
DIGITAL OUTPUT
DIGITAL INPUT
OPTICAL
MD / TAPE
CD-R
DVD
CBL/SAT
CD
CD
DVD
DTV
COAXIAL
LR
O
DVD player
Video
monitor
(U.S.A. model)
Optical out Video out
Audio out
Video in
00_RX-V2400U_EN.book Page 16 Friday, October 10, 2003 10:54 AM

Yamaha RX-V2400 Specifications

General

Type	AV Receiver
Channels	7.1
Total Harmonic Distortion (THD)	0.04%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Surround Sound Formats	Dolby Digital, DTS, Dolby Pro Logic II
Component Video Inputs	3
Component Video Outputs	1
S-Video Inputs	4
S-Video Outputs	1
Tuner	AM/FM
DAC	24-bit/192 kHz
Digital audio input	Optical and Coaxial
Digital audio output	Optical
Video Inputs	Composite, S-Video, Component
Power Output	130 watts per channel (8 ohms, 20 Hz - 20 kHz, 0.04% THD)
Frequency Response	10 Hz - 100 kHz
HDMI Inputs	Not applicable (No HDMI)
HDMI Outputs	Not applicable (No HDMI)
Dimensions	435 x 171 x 400 mm
