Yamaha TDM900 User Manual

6-6
PERIODIC MAINTENANCE AND MINOR REPAIR
6
To install the cowling
Place the cowling in the original posi-
tion, and then install the screws and
the quick fastener.
NOTE:
To install the quick fastener, push the
center pin out so that it will protrude
from the fastener head, insert the fas-
tener into the cowling, and then push
the protruding pin in until it is flush
with the fastener head.
1. Quick fastener
2. Pin
To install the panel
1. Place the panel in the original
position, and then install the
screw.
2. Install the seat and the cowling.
1. Panel B
EAU03317
Panels A and B
To remove one of the panels
1. Remove the corresponding cowl-
ing A or B. (See page 6-5 for
cowling removal and installation
procedures.)
2. Remove the seat. (See page
3-13 for seat removal and instal-
lation procedures.)
3. Remove the screw, and then
take the panel off.
1. Screw
After removal Before installation
5PS-28199-E1 8/29/02 9:16 AM Page 51

Yamaha TDM900 Specifications

General

Displacement	897 cc
Bore x Stroke	92.0 mm x 67.5 mm
Compression Ratio	10.4:1
Fuel System	Fuel Injection
Ignition	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Rear Suspension	Swingarm (monoshock)
Front Tire	120/70 ZR18
Rear Tire	160/60 ZR17
Seat Height	825 mm
Fuel Capacity	20 liters
Wet Weight	223 kg
Length	2, 180 mm
Height	1, 290 mm
Wheelbase	1, 485 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, parallel twin
Front Brakes	Dual 298mm discs
Rear Brakes	245mm disc
Max Torque	88.8 Nm (65.5 lb-ft) @ 6, 000 rpm
