Yamaha TDM900 User Manual

6-14
PERIODIC MAINTENANCE AND MINOR REPAIR
6
8. Remove the coolant reservoir
bolt.
9. Pull the coolant reservoir upward
and away from the motorcycle.
10. Drain the remaining coolant from
the coolant reservoir by opening
the cap, then turning the reser-
voir upside down.
11. Install the coolant reservoir by
placing it in the original position,
then installing the bolt.
12. After the coolant is completely
drained, thoroughly flush the
cooling system with clean tap
water.
1. Bolt
2. Coolant reservoir
13. Install the coolant drain bolts,
and then tighten them to the
specified torque.
NOTE:
Check the washers for damage and
replace them if necessary.
14. Pour the recommended coolant
into the radiator until it is full.
Tightening torque:
Coolant drain bolt:
10 Nm (1.0 m·kgf)
Antifreeze/water mixture ratio:
1:1
Recommended antifreeze:
High-quality ethylene glycol
antifreeze containing corrosion
inhibitors for aluminum engines
Coolant quantity:
Total amount:
1.7 L
Coolant reservoir capacity:
0.25 L
5PS-28199-E1 8/29/02 9:16 AM Page 59

Yamaha TDM900 Specifications

General

Displacement	897 cc
Bore x Stroke	92.0 mm x 67.5 mm
Compression Ratio	10.4:1
Fuel System	Fuel Injection
Ignition	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Rear Suspension	Swingarm (monoshock)
Front Tire	120/70 ZR18
Rear Tire	160/60 ZR17
Seat Height	825 mm
Fuel Capacity	20 liters
Wet Weight	223 kg
Length	2, 180 mm
Height	1, 290 mm
Wheelbase	1, 485 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, parallel twin
Front Brakes	Dual 298mm discs
Rear Brakes	245mm disc
Max Torque	88.8 Nm (65.5 lb-ft) @ 6, 000 rpm
