Yamaha VF150 - Checking Power Trim and Tilt Unit

Operation
58
5. Push the cowling lock levers inward to
secure the top cowling.
6. Check the fitting of the top cowling by
pushing it with both hands. NOTICE: If
the top cowling is not installed cor-
rectly, water can enter the top cowling
and damage the engine, or the top
cowling can blow off at high speeds.
[ECM02371]
EMU46180
Checking power trim and tilt unit
WARNING
EWM04270
 Never get under the lower unit while it is
tilted, even when the tilt support shaft is
installed or the tilt support lever is
locked. Severe injury could occur if the
outboard motor accidentally falls.
 Body parts can be crushed between the
outboard motor and the clamp bracket
when the outboard motor is trimmed or
tilted.
1. Top cowling
2. Protrusion
3. Holder
4. Bottom cowling
1. Top cowling
2. Protrusion
3. Holder
4. Bottom cowling
1. Cowling lock lever
2
3
1
4
ZMU07756
1
2
3
2
3
4
ZMU07757
1
ZMU07758
1. Cowling lock lever
11
ZMU07759
ZMU07760
