Yamaha VF150 - Control Systems

Components
27
EMU40611
Remote control box
The remote control box is equipped with the
remote control lever and electrical switches.
TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
SET MODE
SET MODE
1
76
245
8
12 1411
9
13
3
10
ZMU06899
1. Remote control box (side mount type)*
2. Remote control box (binnacle mount type)*
3. Switch panel (for use with side-mount type)*
4. Switch panel (for use with binnacle type)*
5. Tilt support shaft*
6. Digital tachometer*
7. Digital speedometer*
8. Fuel management meter*
9. Tachometer unit (Square type)*
10.Tachometer unit (Round type)*
11.Speedometer unit (Square type)*
12.Speed & fuel meter unit (Square type)*
13.Speed & fuel meter unit (Round type)*
14.Fuel management meter unit (Square type)*
1. Power trim and tilt switch
2. Remote control lever
3. Free accelerator button
ZMU07022
1
2
3
5
4
6
