Yamaha WaveRunner VXR VX1800A User Manual

Jet pump unit
6-2
Jet pump unit
No. Part name
Q
’ty
Remarks
1 Shift rod joint 1
2 Trim rod joint 1
3Nut 1
4 Washer 2
5 Steering cable joint 1
6 Clamp 1
7 Bilge hose 1
8 Clamp 1
9Bolt 2
M8
× 18 mm
10 Bolt 1
M6
× 30 mm
11 Bolt 4
M10
× 45 mm
12 Dowel pin 2
13 Bolt 2
M8
× 13 mm
14 Washer 2
15 Gasket 2 Not reusable
16 Bracket 1
12
12
11
16
15
14
13
8
4
9
9
3
5
4
1
2
11
11
10
A
LT
572
LT
572
LT
242
1207B
LT
572
7
6
17 Nm (1.7 kgf
·
m, 12.5 ft
·
Ib)
40 Nm (4.0 kgf
·
m, 29.5 ft
·
Ib)7 Nm (0.7 kgf
·
m, 5.2 ft
·
Ib)
15 Nm (1.5 kgf
·
m, 11.1 ft
·
Ib)
2.5 Nm (0.25 kgf
·
m, 1.84 ft
·
lb)

Yamaha WaveRunner VXR VX1800A Specifications

General

Model	WaveRunner VXR VX1800A
Seating Capacity	3
Starting System	Electric
Displacement	1812cc
Fuel Type	Unleaded gasoline
Fuel Delivery System	Electronic Fuel Injection
Rider Capacity	3
Bore x Stroke	86 mm x 78 mm
Fuel Capacity	70.8 L (18.7 US gal)
Height	1.19 m (47 in)
Dry Weight	385 kg (849 lb)
