9-23
9
The oil level should be between the minimum
and maximum level marks.
6. If the oil level is at or below the minimum
level mark, add oil.
Add a sufficient amount to raise to the maxi-
mum level mark, but do not overfill.
7. Install the dipstick.
8. Install the rubber cover.
9. Install the passenger seat cushion.
To change the transmission oil
1. Place an oil pan under the transmission
case to collect the used oil.
2. Remove the transmission oil dipstick.
3. Remove the transmission oil drain bolt
and gasket.
1. Arrow mark
1. Transmission oil drain bolt
2. Gasket
UB4M11E0.book Page 23 Tuesday, August 4, 2020 1:04 PM
