9-45
9
EWB04220
The brake light switch is part of the brake
override system. Improper adjustment
may prevent the brake override system
from working properly.
If necessary, adjust the brake light switch.
1. Hold the brake light switch in place.
2. Turn the adjusting nut in direction (a) to
make the brake light come on earlier.
3. Turn the adjusting nut in direction (b) to
make the brake light come on later.
EBU32561
Cable inspection and lubrication
EWB03380
Damaged cables could restrict operation,
which may cause an accident or injury. In-
spect control cables frequently and re-
place damaged cables. Corrosion can
result when the outer covering of control
cables becomes damaged. Cables can
also become frayed or kinked.
Lubricate the cable ends. If the cables do not
operate smoothly, ask a Yamaha dealer to re-
place them.
1. Brake light switch
2. Adjusting nut
Recommended lubricant:
Yamalube LubezAll
UB4M11E0.book Page 45 Tuesday, August 4, 2020 1:04 PM
