2. Remove the differential gear oil filler bolt
and its gasket, and then check the oil lev-
el. It should be up to the brim of the filler
hole.
3. If the level is low, add sufficient oil of the
recommended type to raise it to the
specified level.
4. Check the gasket for damage, and re-
place it if necessary.
5. Install the differential gear oil filler bolt
and its gasket, and then tighten the bolt
to the specified torque.
Changing the differential gear oil
1. Park the vehicle on a level surface.
2. Place an oil pan under the differential
gear case to collect the used oil.
3. Remove the differential gear oil filler bolt,
the differential gear oil drain bolt and their
gasket to drain the oil.
1. Differential gear oil filler bolt
2. Gasket
3. Differential gear oil
4. Correct oil level
12
3
4
Tightening torque:
Differential gear oil filler bolt:
23 N·m (2.3 kgf·m, 17 lb·ft)
