5-3
5
EBU39340
High beam indicator light “ ”
This indicator light comes on when the high
beam of the headlight is switched on.
EBU39351
Differential gear lock indicator light “ ”
This indicator light comes on when the front
differential gear is locked.
When the On–Command drive knob is set to
“DIFF. LOCK”, the indicator light will flash un-
til the differential is locked. Turn the steering
wheel back and forth or drive slowly to help
the differential gear lock to engage.
EBU37632
Drivetrain icon “ / ”
The drivetrain icon indicates what type of
drive mode is currently selected. When 2WD
is selected, the icon will turn off. When 4WD
is selected, “ ” is displayed. And when 4WD
with differential lock is selected “ ” is dis-
played.
See pages 5-17 and 7-6 for more informa-
tion on selecting the drive mode.
Due to the synchronizing mechanism in the
differential gear case, the drivetrain icon
may not come on until the vehicle starts
moving.
When using the On-Command drive knob
to change to/from “DIFF. LOCK”, the drive-
train icon and the differential gear lock indi-
cator light will flash until the differential gear
is completely locked or unlocked. If the icon
and the indicator light continue to flash, the
differential is not completely locked or un-
locked. In this case, start moving slowly
and/or turn the steering wheel back and
forth to help the differential to lock or un-
lock.
