6-9
6
Tire inspection
When the tire tread depth has worn to 3 mm
(0.12 in) replace the tire. If the tire has a nail or
glass fragments in it, or if the sidewall is
cracked, replace the tire.
OPERATING TIRE PRESSURE (cold):
VEHICLE LOAD of 0.0–200.0 kg (0–441 lb)
FRONT: (Recommended)
100.0 kPa (1.000 kgf/cm², 14.0 psi)
REAR: (Recommended)
100.0 kPa (1.000 kgf/cm², 14.0 psi)
Front: (Minimum)
90.0 kPa (0.900 kgf/cm², 13.0 psi)
Rear: (Minimum)
90.0 kPa (0.900 kgf/cm², 13.0 psi)
VEHICLE LOAD of 200.0–570.0 kg (441–
1256 lb)
FRONT: (Recommended)
100.0 kPa (1.000 kgf/cm², 14.0 psi)
REAR: (Recommended)
220.0 kPa (2.200 kgf/cm², 32.0 psi)
Front: (Minimum)
90.0 kPa (0.900 kgf/cm², 13.0 psi)
Rear: (Minimum)
210.0 kPa (2.100 kgf/cm², 30.0 psi)
Vehicle load is total weight of all occupants,
accessories, cargo, and trailer tongue
weight. Do not exceed maximum vehicle
load of 570.0 kg (1256 lb).
1. Tire tread depth
1
