7 - 16
CHAS
EBS00402
CAUTION:
_
Disc brake components rarely require dis-
assembly.
DO NOT:
• disassemble components unless abso-
lutely necessary;
• use solvents on internal brake compo-
nents;
• use spent brake fluid for cleaning; (use
only clean brake fluid)
• allow brake fluid to come in contact with
the eyes, as this may cause eye injury;
• splash brake fluid onto painted surfaces
or plastic parts, as this may cause dam-
age;
• disconnect any hydraulic connection, as
this would require the entire brake sys-
tem to be disassembled, drained,
cleaned, properly filled and bled after
reassembly.
EBS00404
REPLACING THE FRONT BRAKE PADS
The following procedure applies to both of the
front brake calipers.
NOTE:
_
It is not necessary to disassemble the brake
calipers and brake hoses to replace the brake
pads.
1. Remove:
• brake pads
a
Wear limit
NOTE:
_
Replace the brake pads as a set if either is
found to be worn to the wear limit.
FRONT AND REAR BRAKES
