YMF724 PCI Sound Card Configuration/Hardware
Page -
8
1.7. Connectors for “YMF724 G50”
“YMF724 G50” includes up to eight internal connectors, three external Jack Ports, one
external MIDI/ Joystick connector, one VIDEO connector, one TAD/VOICE Modem
connector, and one PC/PCI Legacy AUDIO SIDEBAND SIGNAL connector.
1.7.1. External Connectors:
J1:..........................
∅
3.5mm Phone Jack for
LINE IN
J2:..........................
∅
3.5mm Phone Jack for
MIC IN
J4:..........................
∅
3.5mm Phone Jack for
AUDIO OUT
J5:.......................... Connector for
MIDI/JOYSTICK
1.7.2. Internal Connectors:
J6:.......................... Internal connector for
LINE IN
(optional)
J7:.......................... Internal connector for
MIC IN
(optional)
J9:.......................... Internal connector for
AUDIO OUT
(optional)
J10:........................ Connector for
CD-AUDIO IN
J11:........................ Connector for
CD-AUDIO IN
J12:........................ Connector for
AUX IN
J13:........................ Connector for
TAD/VOICE MODEM
J14:........................ Connector for
VIDEO IN
J16:........................ Connector for
PC/PCI Legacy Audio SIDEBAND SIGNAL
J19:........................ Connector for
PC SPEAKER
(optional)
J20:........................ Connector for
SPDIF
(optional)
JP1:........................ Jumper for switching between
LINE OUT/SPEAKER OUT
