MAINTENANCE
1
2
3
4
5
6
7
8
9
10
11
7-6
JW3
Use only battery chargers that are
rated for use with 48-volt Yamaha
utility vehicles. Otherwise, serious
battery damage can result.
Thoroughly read and understand
the user manual supplied with
your 48-volt charger.
3. With the charger properly con-
nected and grounded (see
charger’s owner’s manual),
insert the DC output into the DC
charger receptacle.
Do not disconnect the DC output
cord from the DC charger recep-
tacle when the charger is on or an
arc could occur that may cause
an explosion.
1 Red Power ON LED
2 Yellow Charging LED
3 Green Charged LED
4. When the charger is plugged into
the AC power, the Power ON
LED illuminates continuously.
5. If any of the LEDs blink for sev-
eral minutes after the charger is
turned on, there is a problem
with the batteries or the charger.
Contact your Yamaha Dealer.
6. During normal charging, the
Charging LED continually illumi-
nates.
7. The Charged LED illuminates
automatically when the batteries
reach full charge.
