SPECIFICATIONS
9-3
JW3
CHASSIS
Items YTF2E UTILITY VEHICLE
Suspension:
Front Independent (oil-over strut type)
Rear Pivoted trailing arm (mono-link)
Lighting:
Front Dual 35W halogen multi-reflector headlights
Rear Heavy-duty rectangular taillights
Steering system:
Type Rack and Pinion
Steering angle (L.H.) 1.85 turn
Steering angle (R.H.) 1.85 turn
Brakes:
Brake system – front and rear Dual mechanical drum
Type of brake Cable-activated drum brake
Brake pedal free play linkage
adjustment 20-25 mm (0.79-0.99 in.)
(Brake cable end play) 0.1-0.5 mm (0.004-0.02 in.)
Parking brake:
Type Foot type; parking brake with automatic
release.
Release timing
(With pedal segment in second
notch)
(Bolt heads round parallel to arm) 0.0 ~ 0.3 mm (0.000 ~ 0.001 in.)
Wheel:
Tire size:
Front 18 x 8.50–8.00/4-ply turf type
Rear 18 x 8.50–8.00/6-ply turf type
Rim size: 7.00–I–8.00
Tire pressure:
Front 68-82 kPa, 0.69-0.84 kgf/cm
2
(10-12 psi)
Rear 241-255 kPa, 2.5-2.6 kgf/cm
2
(35-37 psi)
Body color: Tortuga
