SWINGARM
4-60
EAS1SL5185
SWINGARM
Removing the swingarm
Order Part name Q’ty Remarks
Use a suitable stand to raise the front wheel
off the ground.
Brake hose holder Refer to “REAR BRAKE” on page 4-21.
Rear brake caliper Refer to “REAR BRAKE” on page 4-21.
Bolt (brake pedal)
Drive chain
1
Collars 2
2
Oil seals 2
3
Thrust bearing 2
4
Bushing 2
5
Oil seals 2
6 Bearing 4
For installation, reverse the removal proce-
dure.
1
2
3
6
4
6
4
1
3
6
2
5
T
.R.
70 Nm (7.0 m
lbf)kgf, 51 ft
T
.R.
4.0 Nm (0.40 m
lbf)
kgf, 2.9 ft
