Instrument and control functions
4-10
4
3. Install the rubber cap.
When turning the damping force
adjuster in direction (a), the 0 click
position and the 1 click position
may be the same.
When turning the damping force
adjuster in direction (b), it may
click beyond the stated specifica-
tions, however such adjustments
are ineffective and may damage
the suspension.
EAU84390
Front fork bleeding
When riding in extremely rough condi-
tions, the air temperature and pressure
in the front fork will rise. This will in-
crease the spring preload and harden
the front suspension. If this occurs,
bleed the air from each front fork leg.
EWA10201
Always bleed both fork legs, other-
wise poor handling and loss of sta-
bility may result.
To bleed the front fork legs
1. Remove the protector.
2. Place the motorcycle on a suitable
stand. (See page 7-26.)
3. Make sure the front wheel is off
the ground and the area near the
bleed screws is clean.
4. Remove the bleed screws.
5. Wait a few seconds, and then in-
stall the bleed screws.
6. Install the protector.
Compression damping setting:
Minimum (soft):
20 click(s) in direction (b)
Standard:
10 (YZ85LWN)
12 (YZ85N) click(s) in direction (b)
Maximum (hard):
1 click(s) in direction (b)
1. Protector
1. Bleed screw
UB4B13E0.book Page 10 Wednesday, August 25, 2021 7:15 AM
