3. COMPONENT NAMES AND FUNCTIONS
Interior Structure & Configuration
Damper fully closed
Damper fully open
Rack
Heater
Rack support
Damper
Cable port
Fan motor
Intake port
Axial fan
Temp control
sensor
Exhaust port
Intake port
Exhaust port
Damper
