6. Fuel Injection equipment
241
6.6 Fuel tank
A triangular 30 liter fuel tank with a 2000mm (78.74
in.) rubber fuel hose to fit all models is available as
an option.
A fuel return connection is provided on top of the
tank of which a rubber hose can be connected to
return fuel from the fuel nozzles.
Sediment
Drain cock
Fuel pipe
Pipe joint
Cock
Tank
To engine
Fuel return
connection
010299-00E
