Function of parts
31
Engine control section
1 Key switch
The key switch is used to start up the engine.
“OFF”: Used to stop the engine.
All this position, no current flows
and the key can be pulled out.
“ON”: Current flows through the switches
of electrical parts. The oil pressure
and charging indicators are lit when
the engine stops.
“START UP”: The starter motor rotates to start up
the engine. Release the key
immediately after start-up of the
engine. The key will automatically
return to the “ON” position for
continuous operation.
2 Accelerator lever
The accelerator lever is used to regulate the engine
speed. Pull the lever backward and push it forward, the
engine speed will decrease and increase respectively.
OFF
ON
START
UP
Low
High
