Table of Contents

COVER1
INTRODUCTION3
- Welcome to the World of Yanmar Tractor3
PICTOGRAPHS4
1. SAFETY PRECAUTIONS11
- About The Operator’s Manual11
- Safety Alert Symbol12
- Precautions Before Operating The Tractor13
- Safe Practices for Operating the Tractor14
- Operate the Tractor on Slopes16
- Travel on a Road17
- Safe Practices for Parking the Tractor17
- Operate the Power Take Off (PTO)18
- Use the 3-Point Hitch18
- Roll-Over Protective Structure (ROPS) Precautions18
- Safe Practices for Servicing the Tractor19
- Replace the rubber product/s such as Hydraulic Hose, Fuel Hoses, Power Steering Hoses, Radiator Hoses and Air Intake Hoses for Every 2 Years20
- This tractor is not designed for forest industry, quarry or mining use20
- Safe Operation of Implements and Attachments21
- Understand the Tractor Safety Decals21
  - Safety Alert Symbol21
  - Care of DANGER, WARNING and CAUTION Decals21
2. SERVICE THE TRACTOR27
3. SPECIFICATIONS29
- Specifications Table29
- Traveling Speeds30
4. IMPLEMENT CAPACITIES31
5. NAMES AND FUNCTIONS OF COMPONENTS33
- Overview33
  - Names of Main Components33
  - Functions of Main Components34
- Operator Station Controls35
  - Names of Components35
  - Function of Components36
- Instrument Panel44
6. PRE-OPERATION CHECK46
- Pre-Operation Check46
- Precautions Before Operation46
- Routine Checks46
- Prevent Damage to Plastic Surfaces and Painted Surfaces46
7. OPERATE THE ENGINE47
- Start the Engine47
- Start the Engine in Cold Weather53
- Shut Off the Engine53
- Restart a Stalled Engine54
- Start When the Engine Runs Out of Fuel55
8. OPERATE THE TRACTOR56
- Accident Hazard56
- Operate a New Tractor57
  - Always run the tractor at less than full speed during the first 50 hours of operation57
  - Change the lubricating oil for the new tractor57
- Raise and Lower the Roll-Over Protective Structure (ROPS)58
  - Lower (folded "down") the Roll-Over Protective Structure (ROPS)58
  - Raise (unfolded "up") the Roll-Over Protective Structure (ROPS)59
- Operate the Tractor60
- Stop the Tractor66
  - Stopping Procedure66
  - Stop in an Emergency67
- Use the Brake68
- Practices for Safe Operation69
9. POWER TAKE OFF (PTO) SYSTEM75
- Operate the Power Take Off (PTO) System75
- Use the Power Take Off (PTO) Safely78
  - Use the Power Take Off (PTO) Shaft Cap78
- Install an Implement to the Power Take Off (PTO) Driveline79
10. 3-POINT HITCH AND DRAWBAR80
- 3-Point Hitch80
- Drawbar85
- Use the Safety Chain86
11. HYDRAULIC SYSTEM88
- 3-point Hitch Control System88
- Operate the Implement Control Valve90
12. TYRES, WHEELS AND WEIGHT94
- Tyres94
- Adjust the Wheel95
- Remove/Install the Wheels97
- Weight (Option)97
13. MAINTENANCE101
- Maintenance Check List101
- Diesel Fuel Specifications103
- Lubricants104
- Replacement Parts105
  - Technical Document105
  - Parts105
14. PERIODIC SERVICE106
- Explosion Hazard106
- n Service the Tractor106
- n Warranty and Repair of the Engine106
  - NEVER inhale the engine exhaust gas.107
- Open/Close the Hood107
  - Open the Hood107
  - Close the Hood108
- Daily Checks108
- Check and Replace as Necessary120
- First 50 Hours121
- Every 50 Hours121
- Every 100 Hours126
  - Service the Air Cleaner Element126
  - Clean the Fuel/Water Separator and Replace the Fuel Filter128
- Every 200 Hours129
- Every 300 Hours131
  - Transmission Hydraulic Oil131
  - Change the Transmission Hydraulic Oil and Replace the Transmission Hydraulic Oil Filters and Clean Transmission Hydraulic Oil Strainer131
- Every 500 Hours133
- Every 1000 Hours136
- Every 1 Year139
  - Replace the Air Cleaner Element139
- Every 2 Years or 2000 Hours139
  - Replace the Thermostat139
- General Maintenance139
15. SERVICE THE ELECTRICAL SYSTEM140
- Battery140
- Fuses143
  - Replace the Accessory Fuses143
  - Check the Alternator Fuse and the Main Fuse143
- Bulb144
- Headlights146
  - Adjust the Headlights146
16. STORAGE147
- Safe Practices for Storage147
- Prepare the Stored Tractor for Operation148
17. TROUBLESHOOTING149
- How to Use the Troubleshooting Table149
18. INDEX160
