XK3190－A12(E)

７

2.3 CONNECTION OF THE INDICATOR

2.3.1 The definition of the connectors on the PCB

(2-2) A12 main board connecting figure

(2-3) A12E main board connecting figure

2.3.2 Load cell connection

indicator load cell

EX- S- SH ⑥ EX+ Excitation＋

⑦ S+

① ②

⑥ ⑦

③ ④

⑧ ⑨

⑤ ②

S-

① EX-

⑨ IN+

EX+ S+ IN- IN+ ⑧ IN-

Excitation－

Load cell output signal＋

load cell output signal－

⑤ SH shield
