Pre-Assembly
PLANNING ASSEMBLY
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
TOOLS REQUIRED
10 mm Wrench 14 mm Wrench
HARDWARE INCLUDED
Part Description Quantity
AA M6x16 Screw 34
BB Ø6 Lock Washer 34
CC M6 Hex Nut 34
DD Ø8 Lock Washer 2
EE M8 Hex Nut 2
FF Ø16 Flat Washer 4
GG Ø3 R Pin 4
HH M8x30 Hex Bolt 2
II Hitch Pin 1
AA BB CC DD EE FF
GG HH II
Claw hammer Safety goggles
Phillips
screwdriver
