12 13
GB GB
Press STOP button to halt the mower at any time.
Return to Docking station
Emergency Stop
Technical Data
Cutting height adjustment
The cutting height can be adjusted by rotating the height adjustment dial located on the top of
the machine. Cutting height range from 20 mm - 55 mm.
NOTE!
We recommend using an ordinary lawn mower or trimmer to cut the lawn below 45 mm
before using the Robotic Mower. This will ensure you get the optimum performance.
1 2
Model Compact 300RBS Compact 400RiS
APP
Max cutting area 300 m
2
400 m
2
Battery pack 20 V/2000 mAh 20 V/2000 mAh
Switch power supply
Input: 100-240 V~, 50/60 Hz,
42 W
Output: 24 V , CC1.5 A
Input: 100-240 V~, 50/60 Hz,
42 W
Output: 24V , CC1.5 A
Power supply model* FY2401500S1/FY2401500S2/
FY2401500S3
FY2401500S1/FY2401500S2/
FY2401500S3
Mowing time on one charge 60 min 60 min
Rated voltage 20 V 20 V
Rated power 42 W 42 W
No load speed 3500 min
-1
3500 min
-1
Cutting width 16 cm 16 cm
Cutting height Approx 20-55 mm Approx 20-55 mm
Charging time 100 min 100 min
Blade model 846210 846210
Weight 8.0 kg 8.0 kg
Frequency Band 0-148.5 kHz 0-148.5 kHz
Magnetic Field Strength 70 dBµA/m 70 dBµA/m
Wireless Frequency Rang/Power
2.4-2.4835 GHz/<0 dBm 2.4-2.4835 GHz/<0 dBm
Max sound pressure level L
pA
=49 dB, K=3 dB L
pA
=49 dB, K=3 dB
Max sound power level L
wA
=60 dB, K=3 dB L
wA
=60 dB, K=3 dB
Degree of protection:
Robotic Mower IP24 IP24
Switching power supply IP67, Plug IP44 IP67, Plug IP44
Spare parts
Spare Blades 3 Pcs 3 Pcs
Boundary pegs 100 Pcs 120 Pcs
Boundary wire 80 m 100 m
Connectors 3 Pcs 3 Pcs
*
WARNING: For the purposes of recharging the battery, only use the detachable supply unit
provided with this appliance.
