13
ADJUSTMENT
Setting the cutting height
As shown in Fig. 11
WARNING! Adjust the cutting height only when the engine is switched off and the
spark plug lead has been removed.
1. The cutting height is centrally adjusted with cutting height adjusting handle. Different
cutting heights can be selected.
2. Pull the adjusting handle out gently and select the desired cutting height.
3. Place the handle in the grove for the desired position and release.
The cutting height range is from 20mm to 75mm in seven steps.
Fig. 11
70mm
20mm
