DESCRIPTION OF PRODUCT PARTS
Check the delivery parts
As shown in Fig. 2
Carefully remove the lawn mower from its packaging and check as the following parts are
complete:
1pc
1pc
1pc
1pc
1pc
2pcs
2pcs
4pcs
4pcs
A. Main mower deck (with upper handle)
B. Grass catcher filter
C. Grass catcher upper cover
D. Grass catcher handle
E. Grass catcher lower case
F. Cross recessed pan head tapping screws ST4.8X25 mm
G. Self tapping screw ST4.8X16 mm
H. Fixing knob with M8 nut
I. Cup head square neck bolts M8X45mm
J. Lower handle
K. Cable clip
L. Spark plug spanner
M. Manual
1pc
WARNING: If any parts are damaged or missing, please contact Action
Spares 1300 418 640. Do not operate this mower until the parts are replaced.
Fig. 2
1pc
1set
1pc
