Yard force GR40 User Manual

22
INSTALLATION
Assemble the lower handle (Fig. C)
Attach the two tooth clamps to the lower handle.
Attach the lower handle to the lawnmower (Fig. D)
Install the lower handle to the lawnmower with two quick release clamps (with fixed in screw).
Make sure that the teeth of fixing gears interlock correctly.
Attach the top handle to the lawnmower (Fig. E)
Mount the top handle to the lower handle by using two quick release clamps (screw with
curved head)
Fitting the cable clip (Fig. F)
Ensure that the cable clips supplied are used to fix the cable to the lower handle
Attach the grass bag
Attach the grass bag to the frame by fixing the plastic hooks onto the side (Fig. G)
Lift the safety flap with one hand and hook in the grass bag. Release the ejector flap to
secure the grass bag in position. (Fig. H&I)

Yard force GR40 Specifications

General

Brand	Yard force
Model	GR40
Category	Lawn Mower
Language	English
