Yard force YF1601 - Page 10

9
ASSEMBLY
NOTE :Make sure the rope guide is on the right handle, when you stand behind
the mower.
Step 2: Unfold the upper handle and x it into place by tighting the star knobs and cup
head square neck bolts (D).
Fig. 4
Step 3: Hold the starter handle and gently pull it out to just over the rope guide ,then hook
it into the rope guide.
Fig. 5
