14
ADJUSTMENT
Setting the cutting height
As shown in Fig 12
CAUTION ! Adjust the cutting height only when the engine is switch off the spark
plug boot has been pulled.
The cutting height is centrally adjusted with cutting height adjusting handle. Different
cutting heights can be selected.
Pull the adjusting handle out and select the desired cutting height. The handle snap into
the desired position.
From position 1 to position 7.The cutting height range from 20mm to 70mm.
Fig. 12
1
2
70mm 20mm
