1. Engine On/Off Control Bar
2. Upper handle
3. Rope guide
4. Handle knob and bolt
5. Recoil starter
6. Oil ler dipstick
7. Side discharge chute
8. Wheel
9. Front bumper
10. Cutting deck
11. Gas ler cap
12. Lower handle
13. Cord clip
14. Bowden cable
PARTS LIST
Carefully remove the lawn mower from its packaging and check that the following parts are included:
A. Main mower deck (with upper handle) 1 pc
B. Wheel 4 pcs
C. Shoulder screw, cupped washer 4 pcs
D. Hand knob and bolt 4 pcs
E. Cord clip 1 pc
F. Lower handle bar 1 pc
G. Wrench 1 pc
H. Engine Oil (SAE 30 15 o.z.) 1 pc
I. Manual 1 pc
WARNING!
If any parts are damaged or missing, do not operate this lawn mower until the missing parts
are replaced.
Failure to heed this warning could result in serious personal injury.
NOTE:
Always recycle the packaging in accordance with local recycling programs.
PARTS LIST
To Next Page
