Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identification ( )
1pc.
- Roof Set
(Y70828-084)
1pc.
- Roof Peak Set
(Y70828-068)
4pc.
Ridge Cap
(Y01028-060)
4pc.
- Left Short Panel
(Y01028-062)
4pc.
- Left Long Panel
(Y01028-064)
1pc.
- Gazebo ID Plaque
(Y70800-104)
4pc.
- Right Short Panel
(Y01028-063)
4pc.
- Right Long Panel
(Y01028-065)
1pc.
- Corner Cap Set (4Pk)
(Y70828-073)
8pc.
Ridge Clip
(Y01028-061)
4pc.
Roof Edge Left
(Y01028-066)
4pc.
Roof Edge Right
(Y01028-067)
1pc.
Peak Cap
(Y01028-071)
1pc.
Peak Post
(Y01028-072)
1pc.
- Weather Seal -
Ridge Clip (8Pk)
(Y70818-074)
1pc.
- Roof To Beam
Bracket Set (12Pk)
(Y70828-102)
1pc.
- Roof To Post
Bracket Set (4Pk)
(Y70828-070)
1pc.
- Post
Mount Set (8Pk)
(Y70819-057)
2pc.
Roof Peak Bracket
(Y00428-068)
1pc.
Carriage Bolt
(Y07428-260)
1pc.
1/4" Nut
(Y08490-200)
1pc.
Spring Clip
(Y09490-001)
1pc.
Peak Loop
(Y20018-003)
1pc.
- 50mm
Hook
(2Pk)
(Y70818-075)
