38 support@yardistrystructures.com
A: From inside the assembly attach Roof to Beam Brackets to Beam Assemblies with one #12 x 1-1/4” Pan
Screw per bracket. (g. 17.1 and 17.2)
Hardware
12 x #12 x 1-1/4” Pan Screw
x 3
Step 17: Secure Roof to Beam Brackets
Inside View
Beam
Assembly
Fig. 17.1
Roof Panel
Assembly
Fig. 17.2
Roof to
Beam
Bracket
#12 x 1-1/4”
Pan Screw
Beam
Assembly
