Yardistry YM12810 - Page 12

12 support@yardistrystructures.com
12 support@yardistrystructures.com
1pc.
Spring Clip
(Y09490-001)
2pc.
- 50mm
Hook
(Y00418-050)
1pc.
1/4" Nut
(Y08490-200)
1pc.
Carriage Bolt
(Y07490-260)
1pc.
Peak Loop
(Y20018-003)
4pc. - Left Long Panel
(Y01030-097)
4pc. - Right Long Panel
(Y01030-098)
4pc. - Left Short Panel
(Y01030-099)
4pc. - Right Short Panel
(Y01030-100)
1pc.
- Corner Cap Set (4Pk)
(Y70830-103)
1pc.
- Gazebo ID Plaque
(Y70800-104)
1pc.
- Roof To Beam
Bracket Set (12Pk)
(Y70829-151)
1pc.
- Post
Mount Set (8Pk)
(Y70819-057)
2pc.
Roof Peak Bracket
(Y00430-068)
1pc. - Roof Set
(Y70830-084)
1pc.
- Roof Peak Set
(Y70830-068)
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identification ( )
4pc.
Ridge Cap
(Y01030-093)
4pc.
Roof Edge Left
(Y01030-091)
8pc.
Ridge Clip
(Y01030-090)
1pc.
Peak Cap
(Y01030-095)
1pc.
- Weather Seal -
Ridge Clip (8Pk)
(Y70818-074)
4pc.
Roof Edge Right
(Y01030-092)
1pc.
Peak Post
(Y01000-094)
1pc.
- Roof To Post
Bracket Set (4Pk)
(Y70829-070)
