Step 26: Attach Eye Lags and Magnet
Part 1
A: Attach one 3/8” Eye Lag to the pilot hole in each (1114) Middle Roof Rafter on both roof assemblies. (F26.1
and F26.2)
Components
5 x 3/8” Eye Lag
Ø3/8 EYE LAG x5
Attach an eye lag to each roof rafter with a hole located
on the bottom face.
Ø3/8 EYE LAG x5
Attach an eye lag to each roof rafter with a hole located
on the bottom face.
(1114)
Middle
Roof
Rafter
F26.1
F26.2
Pilot
hole
3/8” Eye Lag
