model no. 060-2279-2 | contact us: 1.866.523.5218
12
GUARD
• Stop the trimmer.
• Invert the grass trimmer to access the
trimmer head.
• Using a cross-head screwdriver, remove the
pre-installed screws (1) from the trimmer
head.
• Place the guard (2) on to the trimmer head
and turn the guard 45° following the track on
the head.
• Align the screw hole on the guard with the
screw hole on the trimmer head.
• Insert the screw into the trimmer head,
fastening the guard in place.
!
WARNING: To avoid injury, adjust the auxiliary handle for
optimum control and balance. Do not overreach when
operating the grass trimmer. Keep proper balance at all
times for better control of the tool in unexpected situations.
SECURE THE PLUG
• Attach the outlet end of an extension cord to
the plug on the rear of the string trimmer.
• Route the extension cord through the slot
located on the rear of the string trimmer
housing and place underneath the cord
retainer.
SWITCH TRIGGER
CORD WARP
OUTLET
END
2
1
!
NOTE: Use only approved outdoor extension cords.
Assembly
