model no. 060-2279-2 | contact us: 1.866.523.5218 model no. 060-2279-2 | contact us: 1.866.523.5218
13
Assembly
THE CUTTING LINE
• A double-wound spool of monofilament cutting line is pre-installed on the grass trimmer.
When the cutting line needs replacing, install a new spool. Use Yardworks® 60-2269-6
replacement spools.
REMOVE THE SPOOL
• Unplug the extension cord.
• Turn the grass trimmer over to access the spool (2).
• Remove the spool cover by pressing on two tabs parallel to each other on the side of the
cover (1).
• Remove the spool (2) from the spool housing (3).
REPLACE THE SPOOL
• Replace the spool (2) with a new pre-wound spool.
• Insert the end of one line through the opening (4) in the spool housing. Insert the other side
of the line through the other opening (5).
• Align the tabs on the spool cover with the slots in the spool housing on the trimmer head.
• Push down on the spool cover, locking it to the spool housing.
• To advance the line when initially installed, you must pull both sides of the line while
pressing the black line release button on the side of the spool housing (6).
1
2
5
3
6
4
!
WARNING: Do not grasp the exposed cutting line when
picking up or holding the grass trimmer. Before connecting
your grass trimmer to the extension cord, always turn the
switch to the off position. Failure to do so could result in
accidental startup causing serious injury.
