STARTING THE ENGINE
model no. 060-1314-4 | contact us: 1.866.523.5218
24
STARTING THE ENGINE
1. Make sure the engine key
(safety lock out) is inserted into the
keyhole.
2. To start a cold engine: (Fig. 10).
2a. Move the throttle lever (10-1) to full
speed.
2b. Move the choke lever (10-2) to the
choke position.
2c. Move the fuel shut-off lever (10-3)
to the ON position.
2d. Prime 3-5 times.
2e. Move the choke lever (10-2) to
the run position once the engine
begins to run after you pull the
recoil start grip or use the electric
start.
CHOKE
FULL SPEED
FUEL OFF
FUEL ON
RUN
10-1
10-2
10-3
Figure 10
3. To start a warm engine: (Fig. 11).
3a. Move the throttle lever (11-1) to full
speed.
3b. Move the choke lever (11-2) to the
run position.
3c. Move the fuel shut-off lever (11-3)
to the ON position.
3d. Do not prime.
CHOKE
FULL SPEED
FUEL OFF
FUEL ON
RUN
11-2
11-3
11-1
Figure 11
