FIG. B PARTS LIST ENGINE
Item Part Number Description Qty.
1 30913040085000 Hexagon Bolt, M8 × 35, Blue White Zinc 1
2 A26800800202 Spring Washer, 8, Black Zinc 1
3 23032000335000A Thickened Big Washer, Ø8.2 × Ø30 × 3.7, White Zinc 1
4 31013010065000 Flat Key, B4.7 × 4.7 × 70, Black 1
5 23033000415000A Small Belt Pulley, Ø69.5 × 48, Black 1
6 23034000525000A Small Synchronous Pulley Cover, 19 × 50 × 5.8 1
7 23034000075000A Small Synchronous Pulley 1
8 30323060035000 Flange Locking Nut, M8, Hexagon, Blue White Zinc 1
9 23034000565000A Shaft Sheath (Thin), Small Tension Pulley, 18 × 6 1
10 23034000665000A Small Tension Pulley, Ø55 × 22.6 1
11 23034000575000A Shaft Sheath, Small Tension Pulley, 18 × 16.5 1
12 23093000205000A Hexagon Bolt, 30 mm, 5/16" (24UNF-2A), Black Zinc 1
13 23033000075008B Belt Lever, Ø6 1
14 30512050025000 Big Washer, Ø8, Blue White Zinc 1
15 23032001175000A Small Tensioning Plate, T=3, 108.5 × 46.7, White Zinc 1
16 30933010015000 Small Carriage Bolt, M8 × 40, Blue White Zinc 1
17 23093000175000A Hexagon Flange Bolt, 20 mm, 5/16" (24UNF-2A), Black Zinc 2
18 2309800001A Small Tension Pulley Spring, Ø1.5 × Ø11.5 × 56.5, White Zinc 1
19 23034000595000A Small Tensioning Plate Cushion, 308 × 8 1
20 2030100311A Engine, R225S, 224CC 1
