Yardworks 100666 - DRIVETRAIN PARTS LIST (FIG. D)

model no. 060-1314-4 | contact us: 1.866.523.5218 model no. 060-1314-4 | contact us: 1.866.523.5218
45
FIG. D  PARTS LIST  DRIVETRAIN
Item Part Number Description Qty.
1 23033000385000A Housing Connecting Shaft, 10 × 320, Black 1
2 30313090015000 Hexagon Locking Nut, M12, White Zinc 1
3 30512040015000 Flat Washer, 12, d14 × D24 × t2.6, Blue White Zinc 1
4 23038000125000C Extension Spring, Ø8.5 × 44.9, 65Mn 1
5 23035000395000A Friction Disc Bracket, T=2.5, 279 × 220.5, Black 1
6 30413010015000 Elastic Circlips, 40, Black 1
7 A26800405401 Bearing, 6203RS 2
8 23033000395000A Large Synchronous Pulley Shaft, M12 × 44.2, Black 1
9 30213010015000
Cross Recessed Countersunk Head Screw, M5 × 12, Blue White
Zinc
6
10 23032000795000A Large Synchronous Pulley Side Plate, 197 × 8 1
11 23034000505000A Large Synchronous Pulley, 197 × 21 1
12 30323060035000 Flange Locking Nut, M8, Hexagon, Blue White Zinc 7
13 30133020035000 Flange Triangle Self-tapping Screw, M8 × 16, White Zinc 8
14 23052000205000A Bearing Support, T=1.5, White Zinc 4
15 30313090035000 Hexagon Locking Nut, M6, Blue White Zinc 6
16 23052000105000A Pressing Plate, Bearing, T=1.5 mm 2
17 A26800409101 Bearing, Ø25.4 × Ø52 × 15 2
18 23033000485000A Flange Triangle Self-tapping Screw, M6 × 16, White Zinc 14
19 3061301012 Bearing, d12 × D28 × 7 4
20 23035000290027A Housing Assembly, 355 × 285 × 269 1
21 23031000210001A Shift Fork Rod Bushing, PA6+GF30 2
22 23032000655000A Gear Shift Fork Assembly, 267.5 × 134, White Zinc 1
23 23093000055000A R Type Plug Pin, 2 × 26.2 × 7.9, White Zinc 1
24 30813010025000 Open Pin, 2 × 20,White Zinc 1
25 23032000590027A Housing Fixed Plate, 282 × 85 1
26 23041000040001A Waterproof Sheet, PA6+30GF, Black 1
27 23032000615000A Speed Adjustment Cable Support, T=3, 146.4 × 45.5 1
28 A26800307801 Self-tapping Locking Screw, Trigonodont, M6 × 12, Blue White Zinc 2
29 23061000470001A Shift Fork Steering Unit, PA6+GF30 1
30 23041000520301A Shift Fork Cover, HDPE 1
31 22698000065000A B Pin, White Zinc 1
32 23032000510027A Big Bottom Plate, 6 × 280 × 188 1
33 23063000455000A Gear Box Locking Lever, 10 × 280, Zinc, Blue White 1
