FIG. F PARTS LIST CHUTE
Item Part Number Description Qty.
1 23075000210027A Chute Assembly, 453 × 167 × 137, Cool Gray 1
2 A26809000301 Self-plugging Rivet, 4 × 10 × 8.08 7
3 23076000105000A Chute Rubber 1
4 23092000205000A Hinge, 85 × 22, White Zinc 1
5 23075000020027A Discharge Chute Deflector 1
6 23068000185000A Pressing Spring, Ø1.5 1
7 23073000145000A Positioning Rod, Ø8, White Zinc 1
8 23072000105000A Guy Wire Plate, T=3 mm, White Zinc 1
9 30333020025000 Cap Nut, M5, Blue White Zinc 1
10 23075000200265A Chute Support Arm 1
11 23063000565000A Special Bolt, M10 × 40, Black Zinc 1
12 23071000240001A Chute Pivot, PA6+GF30 1
13 30823040035000 Elastic Column Pin, 1.5 × 16, Black 1
14 23072000140265A Chute Pivot Cover, T=2.5, 181.5 × 136.5 × 118.9, Black 1
15 23073000165000A Chute Rotating Cable Support Rod, 208 × 58, White Zinc 1
16 30512050045000 Big Washer, Ø10, Blue White Zinc 2
17 30313090085000 Hexagon Locking Nut, M10, Blue White Zinc 2
18 2306800007A Discharge Chute Deflector Cable 1
19 23032000755000A Chute Rotating Cable, 1203 mm 2
