KNOW YOUR STRING TRIMMER
See Figure 1.
The safe use of this product requires an understanding of the information on the tool and in this operator’s manual as well as a
knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety
rules.
CORD RETAINER
A convenient cord retainer helps keep the extension cord connection secure during string trimmer operation.
EDGER GUIDE
The easily mounted edger guide allows the string trimmer to perform as an edger.
FRONT HANDLE
The string trimmer is equipped with a front handle assembly for ease of operation and to prevent loss of control.
GRASS DEFLECTOR
The trimmer includes a grass deflector that helps protect from flying debris.
ROTATING REAR HANDLE
The rotating rear handle on the string trimmer can be locked in two different positions for ease of use when edging.
TELESCOPING BOOM
The string trimmer can be adjusted to different extension points for ease of use.
7
TOOLS NEEDED
PHILLIPS SCREWDRIVER
Fig. 1
ROTATING REAR
HANDLE
SWITCH
TRIGGER
CORD
RETAINER
TELESCOPING
BOOM
FRONT
HANDLE
EDGER
GUIDE
GRASS
DEFLECTOR
FEATURES
